High Performance CAMC HM13F Series Diesel Generator Engine

Basic Info

Model No.: HM13F

Advantage 1:high power density

Advantage 2:Low Fuel consumption and economical

Advantage 3:Strong environmental adaptability

Advantage 4:Compact structure and convenient maintenance

Advantage 5:Advanced design,high reliability

Advantage 6:First-class quality because of intermationalized supply system

Engine performance parameters
型号Model	单位Unit	HM13F.61230	HM13F.50031	HM13F.61232 HM13F.50033
额定功率/转速 Rated power/Speed	kW/rpm	450/1500	368/1500	450/1800 368/1800
超负荷功率/转速 Overload power/Speed	kW/rpm	505/1500	405/1500	505/1800 405/1800
缸数Number of cylinders		6	6	6 6
缸径x行程BorexStroke	mm	130x161	130x161	130x161 130x161
压缩比Compression ratio		17:1	17:1	17:1 17:1
排量Displacement	L	12.8	12.8	12.8 12.8
比油耗Specific fuel consumption	g/kW ·h	≤184	≤189	≤184 ≤190
机油容量Oil capacity	L	41	41	41 41
排放水平Emission level	-	GB20891中国第三阶段China PhaseⅢ(CM6D30F系列已完成非道路四阶段排放标准认证)
长x宽x高L×W×H	mm	1432×927×1204	1432×927×1204	1432×927×1204 1432×927×1204
重量Weight	kg	1078	1078	1078 1078
推荐组常用功率Recommended Rated power	kW	400	320	400 320
推荐机组备用功率Recommended Overload power	kW	450	370	450 370
